Input Condition

AC100～240V 50/60 Hz  0.15A Max

Input Rated Voltage

100Vac～240Vac

Input Voltage Range

90Vac～264Vac

Input Rated Frequency

50/60Hz

Input Frequency Range

47Hz～63Hz

Input Current

0.3A Max

Input Inrush Current

30A Max

Input No Load Power Consumption

0.5W Max At 115Vac/230Vac

Efficiency

75%  Min

Rated Output Voltage & Current

12V / 2A  24W MAX

Output Line Regulation

±1%

Output Load Regulation

±5%

Output Over Shoot

10% Max

Output Ripple And Noise

1% Max

Output Rising Time

20ms Max At 115Vac

Output Hold up Time

8ms Min At 230Vac

Protection

OCP  OVP  SCP  OPP

Dielectric Withstand Voltage

3KV  5mA  60s

Leakage Current

0.25 mA At 230Vac

DC Plug Specification

5.5*2.1*11H

Dimension

86*44*53mm

Operating Temperature Range

0℃～40℃

Storage Temperature Range

-20℃～+85℃
